Profile plan for HMS 'Amethyst' (1950)
920 x 345 mm
Scale: 1:48. Plan showing the body plan, sheer lines with inboard detail as fitted for Hecla (1798), a 10-gun, ship-rigged bomb vessel (a converted merchant vessel 'Scipio'). The bomb vessel, armed with mortars, was used for bombarding stationary targets including enemy vessels and harbours. Seven bomb vessels were used during the Battle of Copenhagen in 1801, firing over the British and Danish squadrons to attack the warship harbour and defences of Copenhagen itself. The middle deck plan shows the position of the mortars.Object Number: ZAZ5613Date: 1797Original Size: 920 mm x 345 mm
- Full-colour art print
- Reproduced at the same size and scale of the original plan with no border.
- © National Maritime Museum
- Image reference: J1353
